LiFePO4 service battery. Check load current, chargers, available space and model-specific temperature conditions.
Availability and delivery time are confirmed with your quote.
Supplier catalogue reference: 104458
Confirm the included Arctic package and temperature limits: catalogue and PDF differ. This version’s PDF states a 5-year warranty; a 10-year claim from other LIONTRON models is not applied.
Values and conditions come from the attached datasheet; some source wording remains untranslated. Installation settings must match the exact version and its manual.
| Manufacturer model | LIDUCSM12660LX-A |
|---|---|
| EAN / GTIN | 4260704040023 |
| Nominal capacity | 660Ah / 8448 Wh |
| Operating voltage range | 11,0 .. 14,6 V |
| Nominal voltage | 12,8 V |
| Cycle life | ≥8000 bei 80% DoD |
| Charging algorithm | CCCV / IU |
| End-of-charge voltage | 14,2 – 14,6 V |
| Float voltage | 13,5 – 13,8 V |
| Recommended maximum charging current | 50 A |
| Maximum charging current | 210 A |
| Continuous discharge current | 210 A |
| BMS | Integriert |
| Monitoring | Bluetooth 4.0 mit Smartphone App |
| Ingress protection | IP65 |
| Connection | M8 |
| Terminal layout | Pluspol links |
| Manufacturer warranty | 5 Jahre Herstellergarantie |
| Weight (datasheet) | 57 kg |
| Dimensions L × W × H (datasheet) | 365 x 360 x 220 (ohne Anschluss-Schrauben) |
| Application and permitted connection | (Serienschaltung auf bspw. 24V nicht möglich) |
Warranty conditions, permitted use and included equipment depend on the exact version and manufacturer documentation.
Data reviewed 30 October 2026.
Source catalogue ↗
Send the vessel or vehicle model, loads, existing chargers and available space. We will check compatibility and prepare an equipment and installation quote.
