← Back to the rangePERFEKTIUM / Chargers
Chargers

24 V 20 A LiFePO4 charger

Charging equipment for compatible LiFePO4 systems. Confirm output voltage, current and connections for the selected battery.

System voltage
24 V
On requestAvailability on request
Request a quote ↗

Retail price, delivery and lead time are confirmed in your quotation.

Internal catalogue reference: UL-PERFEKTIUM-CHARGER-24V-20A

At a glance

Technical specifications

Manufacturer specifications (EN)

Manufacturer features (EN)
  • 24 V system
  • LiFePO4 charging
Parameter / limitsMin. | Nennwert | Max. | Hinweis
Output voltage16,0 V DC | | 29,2 V DC | Ausgangsbereich per Software stufenlos einstellbar.
Output current0,5 A | | 20 A | Während der Konstantstrom-Ladephase darf der Ladestrom nicht unter 10,0 A liegen.
Efficiency | 91,5 % | | 50-100 % Last, Nenneingangsspannung
Output ripple | | ±1 %±2 % | Effektivwert der Welligkeit: ≤ ±1 %Spitzenwert der Welligkeit: ≤ ±2 %
Output voltage tolerance | | ±1 % | Bei normaler Umgebungstemperatur und konstanter Spannung überschreitet die Abweichung der eingestellten Ausgangsspannung im angegebenen Bereich nicht ±1 %.
Output current tolerance | | +5 %-10 % | Bei 25 °C Raumtemperatur im Konstantstrombetrieb überschreitet die Abweichung des eingestellten Ausgangsstroms nicht +5 % bis -10 %.
UL-PERFEKTIUM-CHARGER-24V-20A

Documents & downloads

Documents are provided in the languages released by the manufacturer. The document title must match the exact model and revision being supplied.

A matching downloadable document is not available in the checked sources. Request the exact-model documentation with your quotation.

Warranty terms vary by product. Refer to the applicable manufacturer document; coverage, installation conditions and exclusions must be checked for your model.

View original product page ↗Manufacturer download centre ↗Source checked: 29 October 2026
