Golf cart batteriesPBG-48-150H-Ultra
Traction batteries for compatible golf carts and electric vehicles. Confirm the controller, charger and peak current requirements.
- System voltage
- 48 V
- Capacity
- 150 Ah
- Chemistry
- LiFePO4
On requestAvailability on request
Request a quote ↗Retail price, delivery and lead time are confirmed in your quotation.
Model / SKU: PBG-48-150H-Ultra
At a glance
Technical specifications
Manufacturer specifications (EN)
Manufacturer features (EN)
- 48 V system
- 150 Ah rated capacity
- Integrated BMS and Bluetooth monitoring
- 300 A continuous discharge
| Nominal voltage / capacity / energy | 51,2 V 150 Ah/7680Wh |
|---|---|
| Manufacturer-stated GEL/AGM replacement capacity | 51,2 V/300 Ah |
| Cell type | Prismatic cells |
| Dimensions including terminals (L × W × H) | 530*360*230mm |
| Weight excluding accessories | 62,6kg |
| Cycle life | >6000@80%D.o.D |
| Internal resistance | ≤14 mΩ |
| Recommended charge voltage | 58.4V |
| Float voltage (standby) | 55.2±0.8V |
| Recommended charge current | 30 A |
| Maximum charge current | 200 A |
| Continuous discharge current | 300 A |
| Peak discharge cut-off current | 450 A (10s) |
| Operating voltage range | 40 – 58.4V |
| End-of-discharge voltage range | 40 – 44.8V |
| Terminal type | M8 |
| Ingress protection | IP54 |
| Charge temperature | 0~45°C |
| Discharge temperature | -20~60°C |
| Storage temperature | 0~40°C |
| Heater operating temperature | -35~5°C |
| Storage maintenance | Recharge every three months |
| Series and parallel connections | Maximum four batteries in series and four in parallel |
| Manufacturer-listed conformity / transport references | CE/UL/UN38.3 /MSDS /ROHS/UN 3480/ CLASS9/ECE R10 |
| Weight | 62,6 kg |
| Dimensions (additional attributes) | 530 × 360 × 230 mm |
| Battery type | Lithium battery |
| Battery terminal | M8 |
| System voltage | 48V |
| Case material | Metall |
| Warranty | 6 years |
| Brand | PERFEKTIUM |
| Nominal capacity | 150Ah |
| Manufacturer-listed conformity / transport references | CE, MSDS, ROHS |
PBG-48-150H-Ultra
Documents & downloads
Documents are provided in the languages released by the manufacturer. The document title must match the exact model and revision being supplied.
App manualEN · BLUETOOTH-PRO-MANUAL-DE
Product catalogueEN · Perfektium product catalogue (English)
DatasheetEN · Perfektium-Lithium-Datasheet-PBG-48-150H-Ultra-EN
ManualEN · Instructions - EN
WarrantyEN · Warranty-PF&PB-EN
DatasheetDE · Perfektium-Lithium-Datenblatt-PBG-48-150H-Ultra-DE
ManualFR · Mode d'emploi - FR
ManualIT · Istruzioni - IT
Warranty terms vary by product. Refer to the applicable manufacturer document; coverage, installation conditions and exclusions must be checked for your model.
View original product page ↗Manufacturer download centre ↗Source checked: 29 October 2026
