PF-Underseat-12-180-CAN

Kompaktne baterije za kampere i ugradnje u kojima raspoloživi prostor određuje izvedbu.

Bluetooth

Na upitDostupnost na upit

Maloprodajna cijena, dostava i rok isporuke potvrđuju se ponudom.

Model / SKU: PF-Underseat-12-180-CAN

Pregled

Tehničke specifikacije

Specifikacije proizvođača (EN)

Značajke proizvođača (EN)

Nominal voltage / capacity / energy	12,8 V 180 Ah/2304Wh
Manufacturer-stated GEL/AGM replacement capacity	12,8 V 360 Ah
Cell type	Prismatic cells
Dimensions including terminals (L × W × H)	355 x 175 x 188mm
Weight excluding accessories	18kg
Cycle life	>6000@80%D.o.D
Internal resistance	≤7 mΩ
Recommended charge voltage	14.6V
Float voltage (standby)	13.8±0.8V
Recommended charge current	54 A
Maximum charge current	90 A
Continuous discharge current	200 A
Peak discharge cut-off current	600 A (200~500ms)
Operating voltage range	10 – 14.6V
End-of-discharge voltage range	10 – 11.2V
Terminal type	SAE-Standard
Ingress protection	IP65
Charge temperature	0~50°C
Discharge temperature	-20~75°C
Storage temperature	-5~35°C
Storage maintenance	Recharge every three months
Series and parallel connections	Maximum four batteries in series and four in parallel
Manufacturer-listed conformity / transport references	CE/UL/UN38.3 /MSDS /ROHS/UN 3480/ CLASS9/ECE R10
Weight	18 kg
Dimensions (additional attributes)	355 × 175 × 188 mm
Battery type	Lithium battery
Battery terminal	SAE
System voltage	12V
Case material	Metall
Warranty	6 years
Brand	PERFEKTIUM
Nominal capacity	180Ah
Manufacturer-listed conformity / transport references	CE, MSDS, ROHS
