PF-Underseat-12-100H

Kompaktne baterije za kampere i ugradnje u kojima raspoloživi prostor određuje izvedbu.

Grijanje Bluetooth

Napon sustava: 12 V
Kapacitet: 100 Ah
Kemija: LiFePO4

Na upitDostupnost na upit

Zatražite ponudu ↗

Maloprodajna cijena, dostava i rok isporuke potvrđuju se ponudom.

Model / SKU: PF-Underseat-12-100H

Pregled

Tehničke specifikacije

Specifikacije proizvođača (EN)

Neki podaci proizvođača nisu usklađeni. Vrijednosti koje treba potvrditi označene su u nastavku, a pogrešno povezani dokumenti izostavljeni. Potvrdite podatke za točnu izvedbu prije ugradnje.

Značajke proizvođača (EN)

12 V system
100 Ah rated capacity
Integrated BMS and Bluetooth monitoring
150 A continuous discharge

Nominal voltage / capacity / energy	12,8 V 100 Ah/1280Wh
Manufacturer-stated GEL/AGM replacement capacity	12,8 V 200 Ah
Cell type	Prismatische Grade-A Zelle
Dimensions including terminals (L × W × H)	355175188mm
Weight excluding accessories	10,2kg
Cycle life	>6000@80%D.o.D
Internal resistance	≤7 mΩ
Recommended charge voltage	14.6V
Float voltage (standby)	13.8±0.8V
Recommended charge current	30 A
Maximum charge current	50 A
Continuous discharge current	150 A
Peak discharge cut-off current	450 A (200~500ms)
Operating voltage range	10 – 14.6V
End-of-discharge voltage range	10 – 11.2V
Terminal type	SAE-Standard
Ingress protection	IP65
Charge temperature	0~50°C
Discharge temperature	-20~75°C
Storage temperature	-5~35°C
Heater operating temperature	-35~5°C
Storage maintenance	Recharge every three months
Series and parallel connections	Maximal 4 Stück in Reihe / 4 Stück in Parallel
Manufacturer-listed conformity / transport references	CE/UL/UN38.3/MSDS/ROHS/UN 3480/CLASS9/ECE R10
Weight	10,2 kg
Dimensions (additional attributes)	355 × 175 × 188 mm
System voltage	12V
Nominal capacity	100Ah
Battery type	Lithium battery
Battery terminal	SAE
Case material	ABS
Warranty	6 years
GTIN	9331615070067
Brand	PERFEKTIUM
Manufacturer-listed conformity / transport references	CE, MSDS, ROHS
